Nominal Size	Pipe OD.	Working  Pressure	Dimensions	Dimensions
mm/in	mm/in	psi/Mpa	L1mm/in	L2mm/in
50×25	60.3×33.7	300Psi 2.07Mpa	82	82
2×1	2.375×1.315		3.23	3.23
50×32	60.3×42.4		82	82
2×1¼	2.375×1.660		3.23	3.23
50×40	60.3×48.3		82	82
2×1½	2.375×1.900		3.23	3.23
65×32	73.0×42.4		95	95
2½×1¼	2.875×1.660		3.74	3.74
65×40	73.0×48.3		95	95
2½×1½	2.875×1.900		3.74	3.74
65×50	73.0×60.3		95	95
2½×2	2.875×2.375		3.74	3.74
65×32	76.1×42.4		95	95
2½×1¼	3.000×1.660		3.74	3.74
65×40	76.1×48.3		95	95
2½×1½	3.000×1.900		3.74	3.74
65×50	76.1×60.3		95	95
2½×2	3.000×2.375		3.74	3.74
80×40	88.9×48.3		108	108
3×1½	3.500×1.900		4.25	4.25
80×50	88.9×60.3		108	108
3×2	3.500×2.375		4.25	4.25
80×65	88.9×76.1		108	108
3×2½	3.500×3.000		4.25	4.25
100×65	108.0×76.1		127	127
4×2½	4.250×3.000		5	5
100×80	108.0×88.9		127	127
4×3	4.250×3.500		5	5
100×50	114.3×60.3		127	127
4×2	4.500×2.375		5	5
100×65	114.3×76.1		127	127
4×2½	4.500×3.000		5	5
100×80	114.3×88.9		127	127
4×3	4.500×3.500		5	5
125×50	133.0×60.3		140	140
5×2	5.250×2.375		5.51	5.51
125×65	133.0×76.1		140	140
5×2½	5.250×3.000		5.51	5.51
125×100	133.0×108.0		140	140
5×4	5.250×4.250		5.51	5.51
125×100	133.0×114.3		140	140
5×4	5.250×4.500		5.51	5.51
125×50	139.7×60.3		140	140
5×2	5.500×2.375		5.51	5.51
125×65	139.7×76.1		140	140
5×2½	5.500×3.000		5.51	5.51
125×80	139.7×88.9		140	140
5×3	5.500×3.500		5.51	5.51
125×100	139.7×114.3		140	140
5×4	5.500×4.500		5.51	5.51
125×50	141.3×60.3	300Psi 2.07Mpa	140	140
5×2	5.563×2.375		5.51	5.51
125×65	141.3×73.0		140	140
5×2½	5.563×2.875		5.51	5.51
125×65	141.3×76.1		140	140
5×2½	5.563×3.000		5.51	5.51
125×80	141.3×88.9		140	140
5×3	5.563×3.500		5.51	5.51
125×100	141.3×114.3		140	140
5×2½	5.563×4.500		5.51	5.51
150×65	159.0×76.1		165	165
6×2½	6.250×3.000		6.5	6.5
150×80	159.0×88.9		165	165
6×3	6.250×3.500		6.5	6.5
150×100	159.0×108.0		165	165
6×4	6.250×4.250		6.5	6.5
150×100	159.0×114.3		165	165
6×4	6.250×4.500		6.5	6.5
150×50	165.1×60.3		165	165
6×2	6.500×2.375		6.5	6.5
150×65	165.1×76.1		165	165
6×2½	6.500×3.000		6.5	6.5
150×80	165.1×88.9		165	165
6×3	6.500×3.500		6.5	6.5
150×100	165.1×114.3		165	165
6×4	6.500×4.500		6.5	6.5
150×125	165.1×139.7		165	165
6×5	6.500×5.500		6.5	6.5
150×50	168.3×60.3		165	165
6×2	6.625×2.375		6.5	6.5
150×65	168.3×76.1		165	165
6×2½	6.625×3.000		6.5	6.5
150×80	168.3×88.9		165	165
6×3	6.625×3.500		6.5	6.5
200×65	219.1×76.1		197	197
8×2½	8.625×3.000		7.76	7.76
200×80	219.1×88.9		197	197
8×3	8.625×3.500		7.76	7.76
200×100	219.1×114.3		197	197
8×4	8.625×4.500		7.76	7.76
200×125	219.1×139.7		197	197
8×5	8.625×5.500		7.76	7.76
200×150	219.1×165.1		197	197
8×6	8.625×6.500		7.76	7.76
200×150	219.1×168.3		197	197
8×6	8.625×6.625		7.76	7.76
250×100	273.0×114.3		229	229
10×4	10.750×4.500		9.02	9.02
250×125	273.0×139.7		229	229
10×5	10.750×5.500		9.02	9.02
250×150	273.0×165.1		229	229
10×6	10.750×6.500		9.02	9.02
